jozoking 48v 24ah lithium battery-0

Lithium & LiFePO4 E-Bike Batteries

Home >  Products >  Power Sports Batteries >  Lithium & LiFePO4 E-Bike Batteries

JOZO GROUP Top Global Batteries Manufacturers

  • Product description
  • Product feature
  • Specifications
  • Related Products

Product description:

JOZOKING E-bike lithium battery has gone through 15 items charging and discharging tests, 27 items cell tests, 46 items BMS tests and 92 items main board tests. The quality is trustworthy.

Brand JOZOKING
Voltage 48V
Capacity 24Ah
Cell IFR21700-3000mAh
Dimensions 230*180*220mm
Weight 9Kg
Cycle Times 1500+
Warranty 5 Years

Product feature:

● High energy density

● Light weight

● No memory effect

● Low self-discharge rate

● Long cycle life

Specifications:

Voltage Capacity Cell Layout Cycle times Constant Discharge Current Weight Dimensions
Length Width Height
48V 12Ah IFR21700-3000mAh 4P15S 1500 15A 5kg 250 141 81
48V 15Ah IFR21700-3000mAh 5P15S 1500 20A 6.5kg 186 155 165
48V 18Ah IFR21700-3000mAh 6P15S 1500 20A 7.5kg 187 155 190
48V 20Ah IFR21700-3000mAh 7P15S 1500 20A 9.5kg 187 155 240
48V 20Ah IFR21700-3000mAh 7P16S 1500 20A 7.5kg 250 180 126
48V 24Ah IFR21700-3000mAh 8P16S 1500 20A 9kg 185 160 265
48V 20Ah ISR 21700-4.0Ah 5P13S 600 20A 5.95kg 140 92 376
48V 24Ah ISR21700-4.0Ah 6P13S 600 20A 7.1kg 140 92 421
48V 28Ah ISR21700-4.0Ah 7P13S 600 20A 8kg 140 92 461
48V 30Ah ISR21700-4.2Ah 7P13S 600 20A 8kg 140 92 461
48V 32Ah ISR21700-4.0Ah 8P13S 600 20A 9.2kg 140 92 491
48V 35Ah ISR 21700-4.2Ah 8P13S 600 20A 9.2kg 140 92 491
60V 20Ah IFR21700-3000mAh 7P20S 1500 35A 10kg 230 185 179
60V 20Ah IFR21700-3000mAh 7P24S 1500 40A 12.5kg 230 185 230
60V 30Ah IFR21700-3000mAh 10P20S 1500 35A 18.2kg 230 185 270
60V 40Ah IFR21700-3000mAh 13P20S 1500 35A 21kg 335 240 170
72V 30Ah IFR21700-3000mAh 10P24S 1500 40A 20kg 250 185 320
72V 40Ah IFR21700-3000mAh 13P24S 1500 40A 25kg 425 240 170
