Home > Products > Power Sports Batteries > Lithium & LiFePO4 E-Bike Batteries
JOZO GROUP Top Global Batteries Manufacturers
JOZOKING E-bike lithium battery has gone through 15 items charging and discharging tests, 27 items cell tests, 46 BMS tests and 92 items main board tests. The quality is trustworthy.
| Brand | JOZOKING |
| Voltage | 48V |
| Capacity | 30Ah |
| Cell | IFR21700-3000mAh |
| Dimensions | 240*132*258mm |
| Weight | 9.5Kg |
| Cycle Times | 1500+ |
| Warranty | 5-6 Years |
● High energy density
● Light weight
● No memory effect
● Low self-discharge rate
● Long cycle life
| Voltage | Capacity | Cell | Layout | Cycle times | Constant Discharge Current | Weight | Dimensions | ||
| Length | Width | Height | |||||||
| 48V | 12Ah | IFR21700-3000mAh | 4P15S | 1500 | 15A | 5kg | 250 | 141 | 81 |
| 48V | 15Ah | IFR21700-3000mAh | 5P15S | 1500 | 20A | 6.5kg | 186 | 155 | 165 |
| 48V | 18Ah | IFR21700-3000mAh | 6P15S | 1500 | 20A | 7.5kg | 187 | 155 | 190 |
| 48V | 20Ah | IFR21700-3000mAh | 7P15S | 1500 | 20A | 9.5kg | 187 | 155 | 240 |
| 48V | 20Ah | IFR21700-3000mAh | 7P16S | 1500 | 20A | 7.5kg | 250 | 180 | 126 |
| 48V | 24Ah | IFR21700-3000mAh | 8P16S | 1500 | 20A | 9kg | 185 | 160 | 265 |
| 48V | 20Ah | ISR 21700-4.0Ah | 5P13S | 600 | 20A | 5.95kg | 140 | 92 | 376 |
| 48V | 24Ah | ISR21700-4.0Ah | 6P13S | 600 | 20A | 7.1kg | 140 | 92 | 421 |
| 48V | 28Ah | ISR21700-4.0Ah | 7P13S | 600 | 20A | 8kg | 140 | 92 | 461 |
| 48V | 30Ah | ISR21700-4.2Ah | 7P13S | 600 | 20A | 8kg | 140 | 92 | 461 |
| 48V | 32Ah | ISR21700-4.0Ah | 8P13S | 600 | 20A | 9.2kg | 140 | 92 | 491 |
| 48V | 35Ah | ISR 21700-4.2Ah | 8P13S | 600 | 20A | 9.2kg | 140 | 92 | 491 |
| 60V | 20Ah | IFR21700-3000mAh | 7P20S | 1500 | 35A | 10kg | 230 | 185 | 179 |
| 60V | 20Ah | IFR21700-3000mAh | 7P24S | 1500 | 40A | 12.5kg | 230 | 185 | 230 |
| 60V | 30Ah | IFR21700-3000mAh | 10P20S | 1500 | 35A | 18.2kg | 230 | 185 | 270 |
| 60V | 40Ah | IFR21700-3000mAh | 13P20S | 1500 | 35A | 21kg | 335 | 240 | 170 |
| 72V | 30Ah | IFR21700-3000mAh | 10P24S | 1500 | 40A | 20kg | 250 | 185 | 320 |
| 72V | 40Ah | IFR21700-3000mAh | 13P24S | 1500 | 40A | 25kg | 425 | 240 | 170 |
